Name: CZ-300E SO2 Salt Spray Composite Corrosion for Test Equipment 220v 1-Year Warranty for Chemical Materials
Brand: Dongguan Zhongzhi Times Test Equipment Co., Ltd.
Availability: InStock

Home Products Corrosion resistance testing machine

CZ-300E SO2 Salt Spray Composite Corrosion for Test Equipment 220v 1-Year Warranty for Chemical Materials

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	ZHONGZHI

Contact Now

Detailed Product Description

Warranty:	1 Year	Customized Support:	OEM, ODM
Power:	4.6KW	Voltage:	220V
Type:	/	Application:	Auto Testing, Plastic Testing, Leather Testing, Process Testing, Laboratory Testing, Lab Testing, Electrical Testing
Product Name:	Sulfur Dioxide Testing Machine	Internal Dimension:	750mm800mm500mm
External Dimension:	1300mm1200mm700mm	Power Supply:	220V 50Hz
Weight:	180kg	Color:	Customer Required
Standard:	DIN 50018, DIN_50017, DIN_EN_ISO_6270-2	Brand:	Zhongzhi Times
Language:	Chineses-English	MOQ:	1 Set

Products Description

Product Introduction

_{This test machine is manufactured with reference to the German standard DIN 50018 for the test of condensed water in an atmosphere containing sulfur dioxide - alternating climate. The sulfur dioxide added at the beginning of the first stage of the test will quickly dissolve in the water on the floor of the test chamber. Therefore, the effective concentration of sulfur dioxide in the air chamber is only about 1/7 of the theoretical concentration at the beginning of the test. Moreover, this initial concentration is not constant in the first stage of the test, but first decreases rapidly and then slowly. At the beginning of the second stage of the test, the heating device will be turned off and the test chamber will be opened for ventilation. After about 1 and a half hours, the required test conditions will be met again according to the requirements of Table 1.}

Specification

Product model	CZ-300E
Nominal content	300L
Inner box size (mm)	750×800×500 W×H×D
Inner box size (mm)	1300×1200×700 W×H×D
Exhaust filter size (mm)	350×500×350 W×H×D
Weight	About 180 kg
Operating noise	≤70db measured at 1 meter in front of the machine and 1.2
Total machine power	4.6KW
Maximum current	21A
Temperature range	RT+5℃～60℃
Humidity range	Constant climate conditions about 100% RH, alternating climate conditions ≤75% RH
Sulfur dioxide concentration	0.05%～1% adjustable
Control accuracy	Temperature resolution: 0.01℃ Temperature deviation: ±1.5℃ Temperature uniformity: ≤2℃ Temperature fluctuation: ±0.5℃
Heating rate	+25℃→+60℃≤35 min
Inner box material	SUS316L stainless steel
Outer box material	Cold rolled steel plate

Test standards

DIN 50018 Condensation in an atmosphere containing sulfur dioxide - Tests in alternating climates DIN_50017_ Climate and its technical applications_Condensation artificial climate test chambers DIN_EN_ISO_6270-2 Condensation climate test test methods

Main spare parts list
Serial No.	Accessory name	Brand	Quantity
1	Temperature controller	Independently developed and manufactured	1 set
2	Laboratory housing	Self-made	1 unit
3	Laboratory chamber	Self-made	1 unit
4	S02 flow meter	Kunlun Industrial Control	1 piece
5	Circuit breaker	Fuji of Japan	1 piece
6	Pure water filter unit	Sanjing	1 set
7	Exhaust fan	SUNON	2 pieces
8	Temperature limiter	Rainbow of Korea	1 set
9	Vacuum pump	Wilt	1 unit
10	Heating tube	Weide	1 piece

Certifications

Company Profile

Workshop Strength

Invention Patent

Packaging & Shipping

Packing: 1. Out packing:Standard export wooden case. 2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners. 3. Checking teams: Specialized staff to inspect and classified your goods. Shipping: You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt ofyour order. It's more preferable for you to provide us with your own FEDEX/DHL account number so that the delivery charge can be charged directly from your account.

FAQ

1. Who are we?
Dongguan Zhongzhi Times Test Equipment Co., Ltd., a subsidiary of Guangdong Zhognzhi Testing Instruments Co., Ltd., was founded in 2005, with 1,2000m² production area and 60+ employees, a leading high-tech enterprise specializing in environmental simulation testing chambers manufacture.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final double inspection before shipment;

3. What can you buy from us?
Salt Spray Test Machine,Rain Test Equipment,Temperature Humidity Test Machine, UV&Xenon Test Equipent, Universal Test Machine. High and low temperature testing chamber, constant temperature and humidity test chamber, etc.

4. Why should you buy from us not from other suppliers?
20+ years test equipment source manufacturer; Reliable quality,one equipment can use over 11+years; 24 hours after-sales online; Various types of different testing equipments.

5. What services can we provide?
Accepted Delivery Terms: FOB, DDP, DDU, CFR, CIF, EXW, Express Delivery;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A, Cash;
Language Spoken: English, Chinese, French
