Name: CZ-120A Coating Material Salt Spray Corrosion Test Machine Salt Fog Test Chamber Salt Spray Corrosion Cabinet
Brand: Dongguan Zhongzhi Times Test Equipment Co., Ltd.
Availability: InStock

Home Products Corrosion resistance testing machine

CZ-120A Coating Material Salt Spray Corrosion Test Machine Salt Fog Test Chamber Salt Spray Corrosion Cabinet

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	ZHONGZHI

Contact Now

Detailed Product Description

Warranty:	1 Year	Customized Support:	OEM, ODM
Power:	5.5KW	Voltage:	220V
Type:	/	Application:	Auto Testing, Laboratory Testing, Lab Testing, Electrical Testing
Protection Class:	/	Product Name:	Salt Spray Test Chamber
Inner Chamber Size:	1600mm500mm1000mm	Test Chamber Temperature:	NSS & AASS 35°C±1°C / CASS 50°C±1°C
Test Chamber Volume:	800L	Salt Spray Pressure:	70~170Kpa
Salt Spray Volume:	1.0~2.0ml/80cm2/h	PH:	6.5~7.2 & 3.1~3.3
Power Supply:	AC220V 20A	Spraying Mode:	Continuous Spraying
Standards:	ASTM.B117 & GB/T2423.17

Products Description

Product Introduction

The Zhongzhi Salt Spray Box Type A series can complete many accelerated corrosion tests, including GJB150.11A-2009, ASTM B117, GB/T2423.17/IEC 60068-2-11, JIS H8502, GB/T10125-2021/1SO9227:2017, and other test methods. Model A salt spray box is our most economical model, which can conduct continuous spray test.

Specification

Model	CZ-60A	CZ-90A	CZ-120A	CZ-160A	CZ-200A
Internal dimensions (cm)	60x40x45	90x50x60	120x50x80	160x50x100	200x60x120
External dimensions (cm)	116x110x60	151x124x80	212x130x125	247x134x145	290x155x165
_{Temperature range of lab}	Saltwater test method (NSS ACSS) 35 ° C ± 1 ° C/Corrosion resistance test method (CASS) 50 ° C ± 1 ° C
_{Pressure bucket temp range}	Saltwater test method (NSS ACSS) 47 ° C ± 1 ° C/Corrosion resistance test method (CASS) 63 ° C ± 1 ° C
Test box capacity	108L	270L	480L	800L	1440L
Salt water tank capacity	15L	25L	40L	40L	40L
_{Salt water concentration}	Sodium chloride solution concentration 5% or sodium chloride solution concentration 5% with 0.26 g of copper chloride (CuCl2 2H2O)added per liter
Compressed air pressure	70~170Kpa
Spray volume	1~2ml/(h · 80cm2) (Collect for at least 16 hours and take the average)
Relative humidity in the lab	Over 85%
PH value	6.5~7.2 3.0~3.2
Spray method	Continuous spray
Power Supply	AC220V1Φ10A			AC220V1Φ20A		AC220V1Φ25A

Test Standers

ASTM B117 Salt spray test

GB/T2423.17/IEC60068-2-11 Salt spray test method

JIS H8502 Corrosion resistance test method for coatings

GB/T10125-2021/ISO9227-2017 Salt water spray test method

GJB150.11A-2009 Environmental test methods for military equipment lab-Salt spray test

List of main equipment parts

No.	Name	Brand	Quantity
1	Laboratory temperature controller	Omron Japan	1 unit
2	Saturated barrel temperature controller	Omron Japan	1 unit
3	Timer	Anliang	1 set
4	Spray tower	Homemade	2 sets
5	Nozzle	Jintan	2 pieces
6	Box	Homemade	1 unit
7	Thermal limiter	Rainbow Korea	2 pieces
8	Laboratory heating tube	Video	2 pieces
9	Pressure barrel heating tube	Video	1 piece
10	Solid state relay	Swiss Carlo Gavazzi	2 sets
11	AC contactor	Schneider	1 piece
12	Intermediate relay	Omron Japan	3 pieces
13	Temperature measuring body	Songqi/Noshi	2 pieces
14	Liquid level reed switch	Fanyi	4 pieces
15	Water supply/spray solenoid valve	Delixi/Instrument Factory 4	4 pieces
16	Pressure regulating valve	Airtac	2 pieces
17	Cylinder	Airtac	2 strips
18	Pressure gauge	Airtac	1 piece
19	Timer	NIPP0N	1 piece
20	Other	Domestic high quality	1 batch

Certifications

Company Profile

Workshop Strength

Invention Patent

Packaging & Shipping

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

FAQ

1. Who are we?
Dongguan Zhongzhi Times Test Equipment Co., Ltd., a subsidiary of Guangdong Zhognzhi Testing Instruments Co., Ltd., was founded in 2005, with 1,2000m² production area and 60+ employees, a leading high-tech enterprise specializing in environmental simulation testing chambers manufacture.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final double inspection before shipment;

3. What can you buy from us?
Salt Spray Test Machine,Rain Test Equipment,Temperature Humidity Test Machine, UV&Xenon Test Equipent, Universal Test Machine. High and low temperature testing chamber, constant temperature and humidity test chamber, etc.

4. Why should you buy from us not from other suppliers?
20+ years test equipment source manufacturer; Reliable quality,one equipment can use over 11+years; 24 hours after-sales online; Various types of different testing equipments.

5. What services can we provide?
Accepted Delivery Terms: FOB, DDP, DDU, CFR, CIF, EXW, Express Delivery;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A, Cash;
Language Spoken: English, Chinese, French
