Name: High-Temperature Aging Test Chamber for Accelerated Thermal Aging and Material Durability Testing
Brand: Dongguan Zhongzhi Times Test Equipment Co., Ltd.
Availability: InStock

Home Products Temperature and humidity testing machine

High-Temperature Aging Test Chamber for Accelerated Thermal Aging and Material Durability Testing

Product Details:

Contact Now

Detailed Product Description

保修期:	1年	支持定做:	OEM, ODM
原产地:	Guangdong, China	品牌:	Zhongzhi
功率:	3.5KW	电压:	220V
类型:	冲击试验机	应用:	塑料测试, 实验室测试, 电气测试, 自动测试
温度范围:	A:200 ℃ B:300 ℃ C:400 ℃ D:500 ℃	加热时间:	RT ~ 100 ℃ 约10分钟
RT ~ 100 ℃ 约10分钟:	0.1 ℃	温度波动:	± 0.5 ℃
温度分布错误:	± 2 ℃	温度测量体:	PT100铂电阻
内盒材料:	不锈钢材料	外箱材料:	A3钢板细粉防静电涂料或不锈钢
绝缘材料:	高密度硅酸铝	玻璃观察窗:	双层防爆窗

Products Description

Product Introduction

Single-door vertical precision high temperature test chamber (environmental aging test chamber) is suitable for baking, drying, curing, heat treatment and temperature aging of LED, LCD, PCB, electronics, electrical appliances, communications, new energy products and materials within temperature.

Specification

Model	SZ-A-72A	SZ-A-150A	SZ-A-270A	SZ-A-480A	SZ-A-1000A
Volume (L)	72	150	270	480	1000
Inner dimensions (mm)	450×400×400	500×600×500	600×900×500	800×1000×600	1000×1000×1000
Outer dimensions (mm)	750×1150×650	800×1250×750	900×1550×750	1100×1650×850	1300×1650×1250
Temperature range	A：200℃ B：300℃ C：400℃ D：500℃
Heating time	RT~100℃about 10 minutes
Temperature resolution	0.1℃
Temperature fluctuation	±0.5℃
Temp distribution error	±2℃
Temp measuring body	PT100 platinum resistor
Inner box material	Stainless steel material
Outer box material	A3 steel plate fine powder anti-static paint or stainless steel
Insulation material	High-density aluminum silicate
Glass observation window	Double-layer explosion-proof window (no observation window above 200°C)
Dynamic test hole	50mm test hole on the left side of the box
Air circulation system	Forced horizontal hot air circulation
Heating system	Built-in nickel-chromium alloy heater, pollution-free and long service life, independent system, does not affect the control circuit
Safety protection	Over-temperature protector, automatic pressure balance protection of the box, heating tube short circuit protection, heating tube overload protection, heating tube and fan interlocking fan does not run and does not heat protection
Sample rack	Fan overload protection, short circuit protection, power supply short circuit protection, power supply overload protection, power supply lack of phase protection, control line overload protection Adjustable sample rack, minimum adjustment spacing 45mm; the tray is made of stainless steel steel bars bent and connected into a tray rack, and 2 tray racks are standardly configured
Power	3.5KW	4.5KW	5.5KW	7.5KW	12KW
Power supply	220V 50HZ	220V 50HZ	220V 50HZ	380V 50HZ	380V 50HZ
Noise	≤70db(A) (1m from the cabinet; measured 1.2m from the ground)
Test chamber	Adjustable over-temperature protector, automatic pressure balance protection of the box
Heating system	Heating tube dry burning protection, heating tube short circuit protection, heating tube overload protection, heating tube and fan interlocking fan non-operation and non-heating protection
Circulating fan	Fan overload protection, short circuit protection
Power control system	Power short circuit protection, power overload protection, power supply phase loss protection, control line overload protection

Test standards

GBT 11158-2008 Technical requirements for high temperature test chambers GBT 2423.2-2008 Environmental testing for electrical and electronic products Part 2: Test methods Test B: High temperature GB/T 30435-2013 Electric drying oven and electric blast drying oven

Certifications

Company Profile

Workshop Strength

Invention Patent

Packaging & Shipping

Packing: 1. Out packing:Standard export wooden case. 2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners. 3. Checking teams: Specialized staff to inspect and classified your goods. Shipping: You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt ofyour order. It's more preferable for you to provide us with your own FEDEX/DHL account number so that the delivery charge can be charged directly from your account.

FAQ

1. Who are we?
Dongguan Zhongzhi Times Test Equipment Co., Ltd., a subsidiary of Guangdong Zhognzhi Testing Instruments Co., Ltd., was founded in 2005, with 1,2000m² production area and 60+ employees, a leading high-tech enterprise specializing in environmental simulation testing chambers manufacture.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final double inspection before shipment;

3. What can you buy from us?
Salt Spray Test Machine,Rain Test Equipment,Temperature Humidity Test Machine, UV&Xenon Test Equipent, Universal Test Machine. High and low temperature testing chamber, constant temperature and humidity test chamber, etc.

4. Why should you buy from us not from other suppliers?
20+ years test equipment source manufacturer; Reliable quality,one equipment can use over 11+years; 24 hours after-sales online; Various types of different testing equipments.

5. What services can we provide?
Accepted Delivery Terms: FOB, DDP, DDU, CFR, CIF, EXW, Express Delivery;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A, Cash;
Language Spoken: English, Chinese, French
