Name: CZ-A-249A Stable Performance Anti-Climate for Test Chamber Plastics & Rubber Corrosion Resistance 220v Voltage
Brand: Dongguan Zhongzhi Times Test Equipment Co., Ltd.
Availability: InStock

Home Products Temperature and humidity testing machine

CZ-A-249A Stable Performance Anti-Climate for Test Chamber Plastics & Rubber Corrosion Resistance 220v Voltage

Product Details:

Contact Now

Detailed Product Description

保修期:	1年	支持定做:	OEM, ODM
原产地:	Guangdong, China	品牌:	ZHONGZHI
功率:	3.6KW	精度:	温度分辨率: 0.01 ℃
电压:	220V	类型:	/
防护等级:	/	产品名称:	冷凝水试验机
内部尺寸:	500830600	外部尺寸:	10001330800
温度范围:	RT + 5 ℃ ~ 60 ℃	材料:	内层不锈钢，外层钢板烤漆
操作系统:	触摸屏可编程控制器	电源:	AC220V/AC380V ± 10% V 50Hz
标准:	DIN_50017/DIN_EN_ISO_6270-2	颜色:	客户要求
最小起订量:	1套

Products Description

Product Introduction

The equipment is used to determine the degree of protection of the product against the intrusion of fine dust; this machine is strictly manufactured in accordance with the protection level test IP5IP6 in EC 60529:2001 and the La2 regulations in IEC 60068-2-68:1994. This test is a test to check the sealing. The sample is exposed to a dusty airflow with a concentration of non-abrasive fine dust less than 75um in size. The sample volume cannot exceed 25% of the internal volume of the test chamber, and the sample base should not exceed 50% of the horizontal working area of the test chamber.

Product Features

1. Can be connected to a computer 2. Condensate is generated evenly, simulating the real environment 3. Touch screen control interface, simple and intuitive operation 4. Support programmed settings and automatic operation 5. One-year warranty

6. Made of high-quality stainless steel, corrosion-resistant and high-temperature-resistant

Specification

Model	CZ-A-249A	CZ-A-500A	CZ-A-1000A	CZ--A
Nominal internal dimensions	249L	512L	1000L	Customized
Inner box dimensions	500x830x600	800x800x800	1000x1000x1000	Customized
Outer box dimensions	1000x1330x800	1300x1330x1000	1500x1530x1200
Temperature range	RT+5℃~60℃ can be freely set
Box material	Inside SUS304# stainless steel, outside cold-rolled steel plate painted
Control system	LCD display touch screen programmable controller
Power supply conditions	AC220V/AC380V±10%V 50Hz single-phase two-wire + protective grounding/three-phase four-wire + protective grounding

Test standards

1) DIN_50017_ Climate and its technical applications-Condensation artificial climate test chamber

2) DIN_EN_ISO_6270-2 Test method for condensation water climate test

Certifications

Company Profile

Workshop Strength

Invention Patent

Packaging & Shipping

Packing: 1. Out packing:Standard export wooden case. 2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners. 3. Checking teams: Specialized staff to inspect and classified your goods. Shipping: You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt ofyour order. It's more preferable for you to provide us with your own FEDEX/DHL account number so that the delivery charge can be charged directly from your account.

FAQ

1. Who are we?
Dongguan Zhongzhi Times Test Equipment Co., Ltd., a subsidiary of Guangdong Zhognzhi Testing Instruments Co., Ltd., was founded in 2005, with 1,2000m² production area and 60+ employees, a leading high-tech enterprise specializing in environmental simulation testing chambers manufacture.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final double inspection before shipment;

3. What can you buy from us?
Salt Spray Test Machine,Rain Test Equipment,Temperature Humidity Test Machine, UV&Xenon Test Equipent, Universal Test Machine. High and low temperature testing chamber, constant temperature and humidity test chamber, etc.

4. Why should you buy from us not from other suppliers?
20+ years test equipment source manufacturer; Reliable quality,one equipment can use over 11+years; 24 hours after-sales online; Various types of different testing equipments.

5. What services can we provide?
Accepted Delivery Terms: FOB, DDP, DDU, CFR, CIF, EXW, Express Delivery;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A, Cash;
Language Spoken: English, Chinese, French
