Name: CZ-V-WIR-24 Electronic Programmable Environmental Walk in Test Chamber
Brand: Dongguan Zhongzhi Times Test Equipment Co., Ltd.
Availability: InStock

Home Products Temperature and humidity testing machine

CZ-V-WIR-24 Electronic Programmable Environmental Walk in Test Chamber

Product Details:

Contact Now

Detailed Product Description

保修期:	1年	支持定做:	OEM, ODM
原产地:	Guangdong, China	品牌:	ZHONGZHI, 中植
功率:	25Kw	精度:	1
电压:	380V	类型:	/
应用:	自动测试	防护等级:	/
产品名称:	步入式恒温恒湿试验箱	温度范围:	RT + 15 ℃ ~ + 100 ℃
试验箱尺寸:	W3000xH2000xD4000mm = 24m ³	门尺寸 (mm):	W2000xH1800
客舱空气压力:	5-50Pa	新鲜空气交换法:	2-10次/小时
电源:	AC380V 50HZ	证书:	ISO CE JJF
最小起订量:	1套

Products Description

Product Introduction

Mainly used to simulate the harsh high temperature or humid environment that electronic instruments, new materials, electrical engineering, vehicles, metals, electronic products, aerospace materials, etc. may encounter during transportation, storage, and use; or in high temperature and humid environment, to test the high temperature resistance, humid and heat resistance of materials, accessories or instruments and equipment and the possible damage and life reduction caused by it!

Specification

Product model	CZ-V-WIR-24
Test chamber dimensions (mm)	W3000xH2000xD4000mm=24m³(can be customized according to customer site conditions)
Door dimensions (mm)	W2000xH1800
Temperature range	RT+15℃～+100℃
Temperature range Temperature uniformity/fluctuation deviation	≤2.0℃/≤±1.0℃/≤±1.0℃
Air pressure in the chamber	5-50Pa
Fresh air exchange law	2-10 times/hour
Top sunlight irradiation system	Infrared, wavelength 280～3000nm, irradiance 350～1200W/㎡, area range: W6500xH3500, meets JAMA/PV3938 standard
Background concentration	1.Benzene content＜0.015；2.Toluene≤0.015；3.Xylene≤0.015； 4.Ethylbenzene ≤ 0.015; 5. Styrene ≤ 0.015; 6. Formaldehyde ≤ 0.015; 7. Acetaldehyde ≤ 0.015; 8. Acrolein ≤ 0.015; 9. TVOC content < 0.350;
Noise	75db(A)
Equipment use environment	Temperature and humidity 0～35℃≤95%RH, ambient air background≤600μg/m³
Startup/operating power	AC380V 50Hz 25KW

Meet the standards for testing methods and equipment execution

ISO/FDIS 12219-2:2011(E) Interior air of road vehicles - Part 2: Airbag method - Method for determination of volatile organic compound emissions from automotive interior parts and materials GB/T 5170.1-2016 Test methods for environmental test equipment Part 1: General

GB/T 5170.2-2017 Test methods for environmental test equipment Part 2: Temperature test equipment

JJF 1101-2019 Calibration specification for temperature and humidity parameters of environmental test equipment

Certifications

Company Profile

Workshop Strength

Invention Patent

Packaging & Shipping

Packing: 1. Out packing:Standard export wooden case. 2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners. 3. Checking teams: Specialized staff to inspect and classified your goods. Shipping: You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt ofyour order. It's more preferable for you to provide us with your own FEDEX/DHL account number so that the delivery charge can be charged directly from your account.

FAQ

1. Who are we?
Dongguan Zhongzhi Times Test Equipment Co., Ltd., a subsidiary of Guangdong Zhognzhi Testing Instruments Co., Ltd., was founded in 2005, with 1,2000m² production area and 60+ employees, a leading high-tech enterprise specializing in environmental simulation testing chambers manufacture.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final double inspection before shipment;

3. What can you buy from us?
Salt Spray Test Machine,Rain Test Equipment,Temperature Humidity Test Machine, UV&Xenon Test Equipent, Universal Test Machine. High and low temperature testing chamber, constant temperature and humidity test chamber, etc.

4. Why should you buy from us not from other suppliers?
20+ years test equipment source manufacturer; Reliable quality,one equipment can use over 11+years; 24 hours after-sales online; Various types of different testing equipments.

5. What services can we provide?
Accepted Delivery Terms: FOB, DDP, DDU, CFR, CIF, EXW, Express Delivery;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A, Cash;
Language Spoken: English, Chinese, French
